PAN / TILT / ZOOM SURVEILLANCE SYSTEM

[info_list icon_bg_color=”#000000″ font_size_icon=”5″ eg_br_style=”none”][info_list_item list_title=”HD resolution (HD-SDI/IP output, crisp high resolution and details)”][/info_list_item][info_list_item list_title=”State of the art long range zoom lense”][/info_list_item][info_list_item list_title=”Image enhancement by poor visibility”][/info_list_item][info_list_item list_title=”Operating temperature: -25 OC + 70 OC (very durable, can be used in multiple environmental conditions)”][/info_list_item][info_list_item list_title=”Touch screen control for easy, intuitive operation (requires DirectShow compatible HD-SDI Frame Grabber)”][/info_list_item][info_list_item list_title=”For observation in applications such as city centers, ports and airports, critical infrastructers, borders, pipelines and wind farms”][/info_list_item][/info_list][info_list icon_bg_color=”#000000″ font_size_icon=”5″ eg_br_style=”none”][info_list_item list_title=”Thermal channel”][/info_list_item][info_list_item list_title=”IR illumination”][/info_list_item][info_list_item list_title=”Image enhancement by poor visibility”][/info_list_item][info_list_item list_title=”Video management software integration”][/info_list_item][/info_list][info_list icon_bg_color=”#000000″ font_size_icon=”5″ eg_br_style=”none”][info_list_item list_title=”High performance pan/tilt head”][/info_list_item][info_list_item list_title=”Long range zoom lens”][/info_list_item][info_list_item list_title=”Camera”][/info_list_item][info_list_item list_title=”Housing”][/info_list_item][info_list_item list_title=”Control software for one or multiple systems”][/info_list_item][/info_list]

[info_list icon_bg_color=”#000000″ font_size_icon=”5″ eg_br_style=”none”][info_list_item list_title=”OTT and side mount”][/info_list_item][info_list_item list_title=”Up to 60/45 degrees per second pan/tilt spee”][/info_list_item][info_list_item list_title=”Up to 60/45 degrees per second pan/tilt spee”][/info_list_item][info_list_item list_title=”Proportional speed control”][/info_list_item][info_list_item list_title=”Unlimited number of preset positions”][/info_list_item][info_list_item list_title=”High accuracy positioning less 0.015°”][/info_list_item][info_list_item list_title=”360° continous rotation”][/info_list_item][info_list_item list_title=”IP68 stainless steel housing, nitrogen purgeable”][/info_list_item][info_list_item list_title=”IP66 pan/tilt housing”][/info_list_item][info_list_item list_title=”Long range zoom lens included”][/info_list_item][info_list_item list_title=”Autofocus”][/info_list_item][info_list_item list_title=”Image Enhancement”][/info_list_item][info_list_item list_title=”Optional Video Tracking”][/info_list_item][info_list_item list_title=”User friendly control software included”][/info_list_item][info_list_item list_title=”Optional Video Tracking”][/info_list_item][info_list_item list_title=”User friendly control software included”][/info_list_item][/info_list][info_list icon_bg_color=”#000000″ font_size_icon=”5″ eg_br_style=”none”][info_list_item list_title=”Newly developed ultra-high sensitivity 2/3 type CMOS sensor Full HD 1080/30p”][/info_list_item][info_list_item list_title=”3D noise reduction: The noise peculiar to CMOS is reduced substantially”][/info_list_item][info_list_item list_title=”Power-saving camera with non-cooling type”][/info_list_item][info_list_item list_title=”Excellent images in 24/7 operation”][/info_list_item][/info_list]

[ultimate_info_table design_style=”design06″ color_scheme=”gray” package_heading=”Pan / Tilt-Head”]

Pan / Tilt Motors	DC stepper motors
Load Mode	Top Load / Side Load
Pan Rotation	360° continuous
Pan Speed	0.005° – 60°/sec (other speed range available under request, e. g. 0,005° – 90°/sec)
Tilt Range	Top Load ±45°; Side Load +90° to -90°
Tilt Speed	0.01° – 45°/sec (other speed range available under request, e. g. 0,005° – 22,5°/sec)
Precision	0,015°
Communication	Ethernet
Protocol	Proprietary Protocol, based on Pelco-D extended
Number of Presets	Up to 250 (unlimited using Absolute Angles Control)
Absolute Angles Control	Support with feedback
Video Output	1x HD-SDI (more options available upon request)
Lightning Protection	Built-in Lightning and Surge Protection, pass EMCtest
Operation Temperature	-25°C to +70°C
Input	24 VDC (+/- 20%) / 100 W – 400 W
IP Rating	IP66
Construction	Al Alloy
Dimensions	206 mm (L) x 345 mm (W) x 390 mm (H)
Additional features	Focal length dependant speed control; Different colours upon request

[/ultimate_info_table][ultimate_info_table design_style=”design05″ color_scheme=”gray” package_heading=”Lens Housing – Nitrogen Pressurisable”]

IP Rating	IEC529 Standard and IP68
Construction	Stainless Steel 316 material
Housing Window Glass	Option 1: Optical tempered hardened glass Option 2: Standard glass with wiper Option 3: Optical tempered hardened glass with wiper (extra charge) When ordering, please specify the desired glass option as subsequent conversion is not possible.
Pressurizing	Recommendend inertial gas: NITROGEN
Safety Capacity	Safety gasket capacity 5 to 30 PSI, default 14.5 PSI
Safety Protected	Auto release gas pressure, when over default value
Heater Function	Optional: Standard turn on at 8°C; turn off at 18°C
Blower Function	Optional: Turn on at >35°C; turn off at 25°C
Dimensions	520 mm (L) x 250 mm (Ø): 670 mm (L) x 254 mm (Ø) w. Sun-Shield
Surface Finishing	Corrosion proof material with post high temperature protection

[/ultimate_info_table][ultimate_info_table design_style=”design05″ color_scheme=”gray” package_heading=”Lens”]

Format / Mount	2/3“ / C-Mount		1/2″ / C-Mount
Internal Extender	–		2.5X
Focal Length (mm)	50 – 1500	25 – 750	w/o Extender: 12 – 660	c/w Extender: 30.5 – 1,680
Iris Range	5 – close	2.5 – close	w/o Extender: 4 – 360	c/w Extender: 10 – 900
Horizontal Angle of View	10.01° – 0.34°	19.76° – 0.69°	w/o Extender: 31.7° – 0.6°	c/w Extender: 12.1° – 0.2°
Iris Control	Auto		Auto
Filter Size (mm)	95		105
Zoom Speed / Focus Speed (sec)	5 sec / 6 sec		4.5 sec / 5 sec
Image Enhancement	HD, Auto Focus, 4 revolving filters		HD, Anti-Fog, Auto Focus, Image Stabiliser

[/ultimate_info_table][ultimate_info_table design_style=”design05″ color_scheme=”gray” package_heading=”System Totals”]

Dimensions	630 mm (L) x 361 mm (W) x 622 mm (H) (w/o Sun Shield)
Weight	~ 50 kg (incl. Lens, Camera etc.)

[/ultimate_info_table][ultimate_info_table design_style=”design05″ color_scheme=”gray” package_heading=”CAMERA”]

Imaging Device	1x CMOS /RGB Bayer
Total pixels	Approx 2.6 megapixels 2270(H)×1144(V)
Valid pixels	Approx 2.2 megapixels 1974(H)×1110(V)
Pixel size	5μm(H)×5μm(V)
Optical sensor	2/3 Type
Scanning system	Progressive
Sensitivity	F11, 2000lx
Minimum Illumination	0.005lxF1.4 1/30 +72dB 50IRE
Viewing resolution	>900TV
Lens	CS-mount
Lens Control	4pin DC Iris control
Electric zoom	x1; x1,1; x1,2; x1,3; … x9,7; x9,8; x9,9; x10
Image display	Standard, Top/Bottom, Left/Right, Top/Bottom and Left/Right Invert
Privacy mask	8Mask GRAY / WHITE / BLACK
Internal test pattern	Color bar, Grayscale, Cross-line
OSD	Operating menu
DC Input Voltage	DC12V ±10% (Ripple 50mVp-p)
Power Consumption	7W
Operating Temp./Humidity	-10 to 50 °C; 35 to 90%
Storage Temp./Humidity	-20 to 60 °C; 20 to 90%
External Dimensions 78.0(W) × 66.0(H) × 139.0(D)mm
Weight	460g

[/ultimate_info_table]

[ultimate_info_table design_style=”design05″ color_scheme=”gray” package_heading=”TECHNICAL SPECIFICATIONS”]

Model	TM30Z5050HDGAIDCPN-IR
Format size	2/3″
Mount	C
Focal	50-1500
length in mm	5.0 – close
Iris range	DC
Iris control	10.01 – 0.34°
Horizontal angle of view	95
Filter size in mm
Zoom Speed	5 sec
Focus Speed	6 sec

[/ultimate_info_table][ultimate_info_table design_style=”design05″ color_scheme=”gray” package_heading=”TECHNICAL SPECIFICATIONS”]

Model	H55ZC-ME-F-HD-PR01	with 2.5x extender*
Format size	1/2″
Mount	C
Focal length in mm12 – 66030.5 – 1,680
Iris range	4 – 360	10 – 900
Iris control	VS
M. O. D.	7 m
Horizontal angle of view	31.6 – 0.6°	12.1 – 0.2°
Filter size in mm	105
Zoom Speed	4.5 sec
Focus Speed	5 sec
* The extender needs 2 seconds to be activated/deactivated

[/ultimate_info_table]

[info_list icon_bg_color=”#000000″ font_size_icon=”5″ eg_br_style=”none”][info_list_item list_title=”1080i -> IP”][/info_list_item][info_list_item list_title=”1080p -> IP”][/info_list_item][info_list_item list_title=”Native IP video stream if network camera is used.”][/info_list_item][/info_list]
